Sensemaking tools

Overview

Jigsaw’s Sensemaking tools help make sense of large-scale online conversations, leveraging LLMs to categorize comments, and summarize comments and voting patterns to surface actionable insights. There are currently three main functions:

• Topic Learning - identifies topics and optionally subtopics from a set of comments.
• Categorization - sorts comments into topics defined by a user or from the Topic Learning function. Comments can belong to more than one topic.
• Summarization - analyzes comments and optionally vote data to output a summary of the conversation, including areas of agreement and areas of disagreement.
  • Voting patterns can be passed in, aggregated either by opinion group or broken down by metadata about participants (e.g. demographic data)
  • Summaries are run through grounding routines, ensuring that claims are backed up by what was actually said in the conversation, and adding citations or references to surface representative comments.

Please see these docs for a full breakdown of available methods and types. These tools are still in their beta stage.

LLMs Used and Custom Models

This library is implemented using Google Cloud’s VertexAI. This means the library can be set up to use any model available on VertexAI’s Google Cloud’s Model Garden, including the latest Gemini models, the open source model Gemma, and other models like Llama and Claude (full list here). The access and quota requirements are controlled by a user’s Google Cloud account.

In addition to models available through VertexAI’s Model Garden, users can integrate custom models using the library’s Model abstraction. This can be done by implementing a class with only two methods, one for generating plain text and one for generating structured data (docs for methods). This allows for the library to be used with models not available in the Model Garden, with other cloud providers, and even with on-premise infrastructure for complete data sovereignty.

Costs of Running

LLM pricing is based on token count and constantly changing. Here we list the token counts for a conversation with ~1000 comments. Please see Vertex AI pricing for an up-to-date cost per input token. As of January 23, 2025 the cost for running topic learning, categorization, and summarization was in total under $1 on Gemini 1.5 Pro.

Token Counts for a 1000 Comment Conversation

	Topic Learning	Categorization	Summarization
Input Tokens	41,000	41,000	19,000
Output Tokens	1,000	26,000	5,000

Running the tools - Setup

First make sure you have npm installed (apt-get install npm on Ubuntu-esque systems).

Next install the project modules by running:
npm install

Using the Default Models - GCloud Authentication

A Google Cloud project is required to control quota and access when using the default models that connect to Model Garden. Installation instructions for all machines are here.

For Linux the GCloud CLI can be installed like:
sudo apt install -y google-cloud-cli

Then to log in locally run:

gcloud config set project <your project name here>

gcloud auth application-default login

Example Usage - Javascript

Summarize Seattle’s $15 Minimum Wage Conversation.

// Set up the tools to use the default Vertex model (Gemini Pro 1.5) and related authentication info.
const mySensemaker = new Sensemaker({
  defaultModel: new VertexModel(
    "myGoogleCloudProject123,
    "us-central1",
  ),
});

// Note: this function does not exist.
// Get data from a discussion in Seattle over a $15 minimum wage.
// CSV containing comment text, vote counts, and group information from:
// https://github.com/compdemocracy/openData/tree/master/15-per-hour-seattle
const comments: Comments[] = getCommentsFromCsv("./comments.csv");

// Learn what topics were discussed and print them out.
const topics = mySensemaker.learnTopics(
  comments,
  // Should include subtopics:
  true,
  // There are no existing topics:
  undefined,
  // Additional context:
  "This is from a conversation on a $15 minimum wage in Seattle"
);
console.log(topics);

// Summarize the conversation and print the result as Markdown.
const summary = mySensemaker.summarize(
  comments,
  // There's vote information so vote tally summarization is the best summarization method to use:
  SummarizationType.VOTE_TALLY,
  topics,
  // Additional context:
  "This is from a conversation on a $15 minimum wage in Seattle"
);
console.log(summary.getText("MARKDOWN"));
Copy

CLI Usage

There is also a simple CLI set up for testing. There are two tools:

• ./runner-cli/runner.ts: takes in a CSV representing a conversation and outputs an HTML file containing the summary. The summary is best viewed as an HTML file so that the included citations can be hovered over to see the original comment and votes.
• ./runner-cli/rerunner.ts: takes in a CSV representing a conversation and reruns summarization a number of times and outputs each of the summaries in one CSV. This is useful for testing consistency.

Running the Checks

In the ./evals directory there are a number of checks that can be run on an unlabeled conversation. There are three categories of checks:

• Monitoring Checks: summary generation failure rate and time to run
• Quick Checks: whether the summary has an intro and conclusion, and whether all the topics and subtopics from categorization are present
• Qualitative Checks: measures how often each group is mentioned

All three checks are run using the ./evals/run_checks.ts script.

Making Changes to the tools - Development

Testing

Unit tests can be run with the following command: npm test

To run tests continuously as you make changes run: npm run test-watch

Documentation

The documentation here is the hosted version of the html from the docs/ subdirectory. This documentation is automatically generated using typedoc, and to update the documentation run:
npx typedoc

Feedback

If you have questions or issues with this library please leave feedback here and we will reach out to you. Our team is actively evaluating Sensemaking performance and is aiming to share our results on this page in the future. Please note that performance results may vary depending on the model selected.

Cloud Vertex Terms of Use

This library is designed to leverage Cloud Vertex, and usage is subject to the Cloud Vertex Terms of Service and the Generative AI Prohibited Use Policy.
